MCD 10080 x-ray baggage scanner for big package port and customs

Tunnel Size: 1000W×1000Hmm Conveyor Speed:   0.2m/s Conveyor Max Load:    800 kg Single inspection dosage:  1.6µGy Wire Resolution:  0.0787mm metal line Steel Penetration:  40-43MM armor plate Film Safety:  ForISO1600 Maximum leakage radiation :             0.1µGY/H ● X-RAY GENERATOR: Orientation:    VerticallyUpward Tube Current:   0.4~1.2MA（adjustable） Anode Voltage:   100~160kV（adjustable） Angle:            80° Generator cooling/working periods:  Sealedoilbathwithforcedair/100％ ● OPERATING ENVIRONMENT:  Storage Temperature:  -20ºCto60ºC Operating Temperature:   0ºCto45ºC Relative Humidity: 20to95%non-condensing System Power:                  220VAC(±10%)50±3HZ Power wastage：       1.0KW(Max) Noise：                     58DB
