mANT Box -15s , Mikrotik Secter antenna #ftth #airfiber #isp #pmwani #pdo #wireless #mikrotik #p2p
#mANTBox 15s #5GHz 120 degree 15dBi dual #polarization sector Integrated #antenna with #720Mhz CPU, 128MB RAM, #SFP, PSU and PoE The #mANTBox is based on our new #mANT sector antennas, but also has a wireless router built right in. Powered by the #RB921 device, the #mANTBox comes ready to use with everything included. The device uses a high speed 720MHz #CPU and has a built in 802.11 #ac/a/n #wireless device with up to 31dBm output power. #mANTBox 15s comes with 15dBi 120 degree sector antenna - #RB921GS-5HPacD-15S-US (USA) is factory locked for 5170-5250MHz and #5725-5835MHz frequencies. This lock can not be removed. - #RB921GS-5HPacD-15S (International) supports #5150MHz-5875MHz range (Specific frequency range can be limited by country regulations). Specifications Details Product code RB921GS-5HPacD-15S Architecture MIPSBE CPU QCA9557 CPU core count 1 CPU nominal frequency 720 MHz Dimensions 140 x 348 x 82 mm #RouterOS license 4 Operating System RouterOS Size of RAM 128 MB Storage size 128 MB Storage type NAND MTBF Approximately 200'000 hours at 25C Tested ambient temperature -40°C to 70°C Suggested price $139.00 Powering Details Number of DC inputs 2 (DC jack, PoE-IN) DC jack input Voltage 9-30 V Max power consumption 13 W Cooling type Passive #PoE in Passive PoE PoE in input Voltage 12-28 V
#mANTBox 15s #5GHz 120 degree 15dBi dual #polarization sector Integrated #antenna with #720Mhz CPU, 128MB RAM, #SFP, PSU and PoE The #mANTBox is based on our new #mANT sector antennas, but also has a wireless router built right in. Powered by the #RB921 device, the #mANTBox comes ready to use with everything included. The device uses a high speed 720MHz #CPU and has a built in 802.11 #ac/a/n #wireless device with up to 31dBm output power. #mANTBox 15s comes with 15dBi 120 degree sector antenna - #RB921GS-5HPacD-15S-US (USA) is factory locked for 5170-5250MHz and #5725-5835MHz frequencies. This lock can not be removed. - #RB921GS-5HPacD-15S (International) supports #5150MHz-5875MHz range (Specific frequency range can be limited by country regulations). Specifications Details Product code RB921GS-5HPacD-15S Architecture MIPSBE CPU QCA9557 CPU core count 1 CPU nominal frequency 720 MHz Dimensions 140 x 348 x 82 mm #RouterOS license 4 Operating System RouterOS Size of RAM 128 MB Storage size 128 MB Storage type NAND MTBF Approximately 200'000 hours at 25C Tested ambient temperature -40°C to 70°C Suggested price $139.00 Powering Details Number of DC inputs 2 (DC jack, PoE-IN) DC jack input Voltage 9-30 V Max power consumption 13 W Cooling type Passive #PoE in Passive PoE PoE in input Voltage 12-28 V
