Connecting and Troubleshooting on a 5S Meter

Join us as we walk through connecting and troubleshooting a 5S meter in the field. We will cover: Connecting your PowerMaster to the service Verifying site accuracy under field condition Troubleshooting a phase fault – missing primary current Troubleshooting a polarity reversal – primary voltage Troubleshooting a polarity reversal – primary current Troubleshooting a phase reversal – secondary current Troubleshooting a cross phase – secondary current Simulations of both 3-Wire Delta and Single Phase 3-Wire
